Mig 400 Welding Machine

Mig 400 Welding Machine Specification

Voltage
220 Volt (v)

Function
Semi Automatic

Efficiency
High

Usage
Industrial

Condition
New

Cooling Method
Air Cooling

Motor Type
Electric

Mig 400 Welding Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Mig 400 Welding Machine

The Mig 400 Welding Machine is a high efficiency and semi automatic welding equipment that is perfect for industrial usage. With its air cooling method and electric motor type, this machine provides utmost convenience and ease of use. It operates on a voltage of 220 Volt (v) and ensures smooth and precise welding performance. This welding machine is built to last and comes in a brand new condition that is ready to use. Whether you are a manufacturer, supplier, trader or wholesaler, this machine is a perfect fit for all your welding needs.

Feature

Full bridge soft switch technology, high reliability and less energy Consumption; over-heat & over current protection.
Equipped with MIG and MMA combination enabling Multiple functions and high cost effectiveness.
Post welding wire ends drop elimination function, soft start wire feeding, high arc ignition successful rate.
Unique welding dynamics control circuit: less spatter, fine welding bead and high welding efficiency.
Aprompt feedback circuit that provides for stable arc can keep electric arc adjusted responsively as wire stick-out varies.
Unique dynamics characteristic control circuit
Adjustable inductance for controlling Arc to optimize to weld performance.
International Standard IEC 60974-1

Specifications Standard

MIG/MAG/MMA
Gas/Gasless FCAW
2T/aT
Built-in Hot start & arc force
Built-in Hot Start
Adjustable inductance knob
Inching
Gas check
Digital Display for current & voltage

Accessories Standard

1 set wire feeder with 35 mm2 cable
3MQTB 850 Torch
400A clamp-35mm2 cable 1m
1 pc quick plug
36V CO2 regulator with heater
JS 36 KD Torch with Euro Adaptor - (Optional)

Model	MIG 400 N361
Input power source	3-AC380V -/+15% 50/60 Hz
Rated input currant (A)	25.1
Rated input power capacity (KVA)	17.8
Power factor	0.9
No- fond voltage (V)	62
Rated output (A/V)	400/36
Welding voltage (V)	15.5-40
Welding current (A)	30-400
Wire speed (m/min)	1.5-22
Output characteristics	MMA: CC MIG/MAG: CV
Raled duty cycle (%) @40 deg C	MIG: 100 MMA:80
Efficiency %	85
Protection class	IP21S
Insulation class	F
Dimensions mm	595x285x470
Weight (Kg)	45
